Mini Powder Coating System COLO-800DT-B

Comes with 2 lbs fluidizing cup working with mini quantity of powder, ideal for powder coating mini parts, sample testing or laboratory use, with advantages of simple cleaning and fast color change.
COLO-800D series with intelligent functions and excellent performance ensures great powder coating efficiency.
  • COLO-800DT-B

  • COLO


Mini Powder Coating System COLO-800DT-B

Intelligent Controller Features

colo 800d powder coating system

1) Voltage can be adjusted by buttons from 0-100kv, the voltage and amperage values will be precisely shown on the digital display. Powder output air and atomization air are easily regulated by pressure valves.

2) Users are able to freely switch modes between three preset programs, flat coating, corner coating and recoating, suitable for beginners handling most shape of workparts.

Flat coating: ideal for flat shape workpieces.

Corner coating: ideal for complex shape parts with deep corners.

Recoating: ideal for repairing coating with second time.

Electrostatic Spray Gun Features

powder coating gun

1) 100 kV powder spray gun maximizes powder charging capacity, and always maintains highest transfer efficiency even after long time use, most powders are attracted to the metal parts with least material waste.

2) The lightweight and ergonomic design enables you to do jobs at ease. We use high quality engineering materials for less wear and longer life.

3) Comes with full array of nozzle assortment for optimal effect , including flat nozzles, round nozzles with a series of deflectors, as well as extension nozzles for better penetration of corners.

Powder Coating Fluidizing Cup Features

powder coating gun hopper

1) Size: D10xH20cm, 2 Ibs mini hopper is ideal very small series production of powder testing, laboratory use.

2) The hopper can be quickly detached into small pieces for easy cleaning during color change, as well as assembled without any tools.

3) Incorperates with fluidizing plate which allows powders easily to be conveyed from the hopper to the gun with a high degree of uniformity and consistency

4) Powders stored in a well-sealed hopper will maintain a dry condition without moist, which is important to get a uniform powder output cloud and quality finishing results

COLO-800DT-B Mini Powder Coating System Components

1. COLO-800D Digital Intelligent Controller

2. COLO-08 Light weight 100kv manual powder gun with 5m cable

3. Nozzle assortment, including fan spray nozzles, round nozzles with deflectors, extension nozzles.

4. Fluidizing well-sealed powder coating cup, 2lbs capacity

5. COLO self-designed owder injectors for smooth and uniform output

6. Powder hose 5 meters, anti-static material

7. Oil-water separating filter

8. Other installation connections and tools
