Digital Powder Coating Thickness Tester COLO-8856FN

Digital, easy-to-use thickness gauge accurately tests the surface thickness of painting or powder coating.
  • COLO-8856FN

Availability:
Digital Powder Coating Thickness Tester COLO-8856FN
Digital Powder Coating Thickness Tester COLO-8856FN


Specifications & Configurations

Display: 4 digits LCD, backlit

Range: 0~1250 μm/0~50mil (other ranges can be specified )

Min.radius workpiece: F: Convex 1.5mm/Concave 25mm

 N: Convex 3mm/ Concave 50mm

Min. measuring area: 6mm

Min.Sample thickness : 0.3mm

Resolution: 0.1 μm (0~99.9μm); 1 μm (over 100μm)

Accuracy: ±1~3%n or 2.5 μm or 0.1mil (Whichever is the greater)

Bttery Indicator: Low batter indicator.

PC interface: with USB interface.

Power supply: 2x1.5 AAA(UM-4) battery.

Operating condition: Temp. 0~50°C . Humidity<95% .

Size: 126x65x35 mm;  5.0x2.6x1.6 inch.

Weight: about 81g (not including batteries)
